| Part No. | Name | Qty | Page |
|---|---|---|---|
| 8T-4205 |
WASHER-HARD (7.2X14.5X2-MM THK)
硬垫圈 |
1 | 921 |
| 1H-3244 |
LOCKWASHER
锁紧垫圈 |
1 | 921 |
| 6V-8187 |
NUT (1/4-28-THD)
调速螺母 |
1 | 921 |
| 292-3815 |
KIT-TERMINAL
|
2 | 921 |
| 9L-6770 |
CAP-DUST
防尘罩 |
1 | 921 |
| 5P-3419 |
RACE-BEARING INNER
|
1 | 921 |
| 291-8247 |
RECTIFIER AS
|
1 | 921 |
| 202-2708 |
DIODE AS
二极管组件 |
1 | 921 |
| 3T-6354 |
REGULATOR AS-VOLTAGE (24-VOLT) (ALTERNATOR)
|
1 | 921 |
| 291-8253 |
CAPACITOR AS
|
1 | 921 |
| 202-9897 |
BEARING-SPECIAL BALL
|
1 | 921 |
| 100-6531 |
FAN-ALTERNATOR (11-BLADE)
|
1 | 921 |
| 187-2034 |
NUT-FLANGE (5/8-18-THD)
|
1 | 921 |
| 291-8274 |
PLATE
凸轮斜盘 |
1 | 921 |
| 291-8271 |
HOUSING AS
壳体组件 |
1 | 921 |
| 202-2700 |
FRAME
机架 |
1 | 921 |
| 291-8263 |
STATOR AS
定子组件 |
1 | 921 |
| 6N-1945 |
COIL AS-FIELD
磁场线圈组件 |
1 | 921 |
| 9S-2390 |
RETAINER
固定器 |
1 | 921 |
| 9S-2302 |
ROTOR AS
转子组件 |
1 | 921 |
| 4B-2047 |
NUT (10-24-THD)
调速螺母 |
1 | 921 |
| 8T-0328 |
WASHER-HARD (5.5X10X1-MM THK)
硬垫圈 |
1 | 921 |
| 8F-1434 |
LOCKWASHER
锁紧垫圈 |
1 | 921 |
| 202-2784 |
KIT-ALTERNATOR TERMINAL
|
1 | 921 |
| 202-2785 |
KIT-ALTERNATOR TERMINAL
|
1 | 921 |
| 202-2786 |
KIT-ALTERNATOR TERMINAL
|
1 | 921 |
