| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 3B-8489 |
FITTING
接头 |
5 | 813 |
| 093-0349 |
WASHER
卡箍板 |
1 | 813 |
| 166-1496 |
SEAL
O 形密封圈 |
4 | 813 |
| 189-3922 |
PIN
U 形夹销 |
1 | 813 |
| 201-2771 |
WASHER (OD=90.00mm)
止推垫圈 |
1 | 813 |
| 201-2836 |
BOLT (L=200mm)
螺栓 |
1 | 813 |
| 241-7129 |
LINK
连杆 |
1 | 813 |
| 8T-5460 |
BOLT (L=40mm)
螺栓 |
1 | 813 |
| 241-7150 |
LINK AS
连杆组件 |
1 | 813 |
| 251-2552 |
PIN AS
弹簧销组件 |
1 | 813 |
| 251-2557 |
PIN
U 形夹销 |
1 | 813 |
| 251-2558 |
PIN AS
弹簧销组件 |
1 | 813 |
| 093-1345 |
SEAL-O-RING (ID=155.00mm)
O 形密封圈 |
2 | 813 |
| 166-1488 |
SHIM (T=2.00mm)
调整垫片 |
2 | 813 |
| 166-1495 |
SEAL
O 形密封圈 |
2 | 813 |
| 186-5649 |
BOLT (L=160mm)
螺栓 |
1 | 813 |
| 8T-4001 |
NUT
螺母 |
2 | 813 |
| 8T-4123 |
WASHER
卡箍板 |
1 | 813 |
| 8T-4131 |
NUT
螺母 |
2 | 813 |
| 8T-4167 |
WASHER
卡箍板 |
1 | 813 |
| 8T-5379 |
BOLT (L=50mm)
螺栓 |
1 | 813 |
| 241-7140 |
LINK AS
连杆组件 |
1 | 813 |
