| Part No. | Name | Qty | Page |
|---|---|---|---|
| 143-9549 |
HOSE AS
软管组件 |
1 | 421 |
| 143-9550 |
HOSE AS
软管组件 |
1 | 421 |
| 143-9551 |
HOSE AS
软管组件 |
1 | 421 |
| 143-9548 |
HOSE AS
软管组件 |
2 | 421 |
| 2D-1683 |
FITTING
接头 |
3 | 421 |
| 5P-9085 |
CLIP
卡箍 |
3 | 421 |
| 8T-4191 |
BOLT (L=16mm)
螺栓 |
3 | 421 |
| 8T-4121 |
WASHER
卡箍板 |
5 | 421 |
| 7K-1181 |
STRAP
接地束带 |
3 | 421 |
| 143-9566 |
PUMP AS
水泵组件 |
1 | 421 |
| 117-4345 |
SUPPORT AS
支承组件 |
1 | 421 |
| 8T-7547 |
BOLT (L=30mm)
螺栓 |
2 | 421 |
| 5C-7261 |
NUT
螺母 |
2 | 421 |
| 8T-4224 |
WASHER
卡箍板 |
2 | 421 |
| 8T-4139 |
BOLT (L=30mm)
螺栓 |
3 | 421 |
| 5P-1076 |
WASHER
卡箍板 |
3 | 421 |
| 143-9552 |
CONNECTOR
接头 |
1 | 421 |
| 118-6052 |
SLEEVE
套筒 |
3 | 421 |
| 123-5588 |
NUT
螺母 |
1 | 421 |
| 118-6051 |
NUT
螺母 |
2 | 421 |
| 118-6057 |
SLEEVE
套筒 |
2 | 421 |
| 118-6058 |
CONNECTOR
接头 |
2 | 421 |
| 108-6711 |
SLEEVE
套筒 |
2 | 421 |
| 108-6712 |
CONNECTOR
接头 |
2 | 421 |
| 108-6714 |
NUT
螺母 |
2 | 421 |
| 143-9546 |
TUBE
管子 |
1 | 421 |
| 143-9547 |
TUBE
管子 |
1 | 421 |
| 108-6710 |
CONNECTOR AS
接头组件 |
2 | 421 |
| 108-6717 |
ELBOW AS
弯头组件 |
1 | 421 |
| 6V-8653 |
BOLT (L=40mm)
螺栓 |
2 | 421 |
| 9X-8256 |
WASHER (6.6X12X2-MM THK)
止推垫圈 |
2 | 421 |
| 110-9851 |
BOLT
特种螺栓 |
2 | 421 |
| 109-8708 |
CLAMP
V 形带箍 |
1 | 421 |
| 118-6049 |
PLUG
O 形圈螺塞 |
8 | 421 |
| 118-6050 |
WASHER
卡箍板 |
8 | 421 |
| 126-5165 |
VALVE
切断阀 |
1 | 421 |
| 108-6709 |
CONNECTOR AS
接头组件 |
5 | 421 |
| 3B-8489 |
FITTING
接头 |
1 | 421 |
| 8T-4136 |
BOLT (L=25mm)
螺栓 |
2 | 421 |
| 133-4603 |
SUPPORT AS
支承组件 |
1 | 421 |
| 6K-6967 |
ADAPTER-PIPE
|
2 | 421 |
| 150-7430 |
SUPPORT AS
支承组件 |
1 | 423 |
| 127-5266 |
GUN AS
|
1 | 423 |
