| Part No. | Name | Qty | Page |
|---|---|---|---|
| 3N-2451 |
JOINT AS-TUBE
|
4 | 263 |
| 9X-7537 |
SEAL
O 形密封圈 |
2 | 263 |
| 4P-3117 |
VALVE-BALL
|
1 | 263 |
| 4W-0530 |
RING-RETAINING
挡圈 |
2 | 263 |
| 4W-0531 |
RETAINER
固定器 |
4 | 263 |
| 5P-8154 |
JOINT AS-TUBE
|
2 | 263 |
| 9X-7526 |
SEAL
O 形密封圈 |
2 | 263 |
| 6V-1581 |
CLIP (SLOT)
卡箍 |
1 | 263 |
| 6V-1582 |
CLIP (TAB)
卡箍 |
1 | 263 |
| 127-4230 |
SEAL
O 形密封圈 |
2 | 263 |
| 120-9678 |
BRACKET
支架 |
1 | 263 |
| 126-5613 |
FLANGE
半边 |
2 | 263 |
| 126-5957 |
ELBOW
弯头 |
1 | 263 |
| 249-0029 |
MOUNTING GP-RADIATOR
|
1 | 263 |
| 3B-7749 |
NIPPLE-PIPE
管接头 |
1 | 263 |
| 4L-6454 |
BOLT (3/8-16X1-IN)
螺栓 |
4 | 263 |
| 4L-9337 |
BOLT (3/8-16X1.5-IN)
螺栓 |
1 | 263 |
| 5P-2228 |
BOLT (1/2-13X1-IN)
螺栓 |
1 | 263 |
| 6V-3835 |
SEAL-O-RING
O 形密封圈 |
1 | 263 |
| 6V-8188 |
NUT (1/2-13-THD)
调速螺母 |
8 | 263 |
| 6V-8801 |
NUT (3/8-16-THD)
调速螺母 |
1 | 263 |
| 7X-0300 |
BOLT (3/8-16X6.5-IN)
螺栓 |
2 | 263 |
| 8T-1919 |
SEAL-O-RING
O 形密封圈 |
2 | 263 |
| 8T-4223 |
WASHER
卡箍板 |
1 | 263 |
| 8T-4835 |
BOLT (1/2-13X2-IN)
螺栓 |
8 | 263 |
| 8T-4896 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
硬垫圈 |
6 | 263 |
| 9B-7237 |
BOLT (3/8-16X1.25-IN)
螺栓 |
5 | 263 |
| 9Y-6893 |
GASKET
密封垫 |
2 | 263 |
