| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 7X-1448 |
ELBOW
弯头 |
2 | 544 |
| 9N-3666 |
VALVE-MANUAL (COOLANT CONDITIONER)
|
2 | 544 |
| 9Y-3205 |
COOLANT CONDITIONERGP
|
1 | 544 |
| 003-7764 |
END
软管接口 |
1 | 544 |
| 030-0709 |
FITTING (45-DEG ELBOW)
直接头 |
1 | 544 |
| 255-4653 |
BRACKET AS
支架组件 |
1 | 544 |
| 1F-0750 |
NUT-WELD (3/8-16-THD)
焊接螺母 |
2 | 544 |
| 0S-1594 |
BOLT (3/8-16X1-IN)
螺栓 |
2 | 544 |
| 0S-1617 |
BOLT (5/16-18X0.75-IN)
螺栓 |
2 | 544 |
| 109-1145 |
CLAMP-HOSE
软管卡箍 |
4 | 544 |
| 2P-8421 |
ADAPTER-O-RING
|
2 | 544 |
| 3D-2824 |
SEAL-O-RING (ID=23.47mm)
O 形密封圈 |
3 | 544 |
| 3J-1907 |
SEAL-O-RING (ID=11.89mm)
O 形密封圈 |
2 | 544 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
硬垫圈 |
2 | 544 |
| 8T-6767 |
PLUG-PIPE
管螺塞 |
2 | 544 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
硬垫圈 |
2 | 544 |
| 9S-8008 |
PLUG-O-RING
O 形圈螺塞 |
1 | 544 |
| 4K-9097 |
NUT-WELD (5/16-18-THD)
焊接螺母 |
2 | 548 |
| 0S-1618 |
BOLT (5/16-18X1-IN)
螺栓 |
2 | 548 |
| 7X-1448 |
ELBOW
弯头 |
2 | 540 |
| 9N-3666 |
VALVE-MANUAL (COOLANT CONDITIONER)
|
2 | 540 |
| 9Y-3205 |
COOLANT CONDITIONERGP
|
1 | 540 |
| 003-7764 |
END
软管接口 |
1 | 540 |
| 030-0709 |
FITTING (45-DEG ELBOW)
直接头 |
1 | 540 |
| 255-4653 |
BRACKET AS
支架组件 |
1 | 540 |
| 1F-0750 |
NUT-WELD (3/8-16-THD)
焊接螺母 |
2 | 540 |
| 0S-1594 |
BOLT (3/8-16X1-IN)
螺栓 |
2 | 540 |
| 0S-1617 |
BOLT (5/16-18X0.75-IN)
螺栓 |
2 | 540 |
| 109-1145 |
CLAMP-HOSE
软管卡箍 |
4 | 540 |
| 2P-8421 |
ADAPTER-O-RING
|
2 | 540 |
| 3D-2824 |
SEAL-O-RING (ID=23.47mm)
O 形密封圈 |
3 | 540 |
| 3J-1907 |
SEAL-O-RING (ID=11.89mm)
O 形密封圈 |
2 | 540 |
| 5M-2894 |
WASHER-HARD (10.2X18.5X2.5-MM THK)
硬垫圈 |
2 | 540 |
| 8T-6767 |
PLUG-PIPE
管螺塞 |
2 | 540 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
硬垫圈 |
2 | 540 |
| 9S-8008 |
PLUG-O-RING
O 形圈螺塞 |
1 | 540 |
| 6V-3250 |
SEAL-O-RING
O 形密封圈 |
1 | 544 |
| 4K-9097 |
NUT-WELD (5/16-18-THD)
焊接螺母 |
2 | 544 |
| 0S-1618 |
BOLT (5/16-18X1-IN)
螺栓 |
2 | 544 |
| 357-4589 |
ADAPTER AS
接头组件 |
2 | 544 |
| 6V-5063 |
SEAL-O-RING
O 形密封圈 |
1 | 544 |
