| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 3T-3434 |
PLUG
O 形圈螺塞 |
6 | 546 |
| 7T-3279 |
HOUSING AS
壳体组件 |
1 | 546 |
| 8T-8566 |
TERMINAL AS
端子组件 |
1 | 546 |
| 6V-8188 |
NUT (1/2-13-THD)
调速螺母 |
4 | 546 |
| 7X-0562 |
WASHER-HARD (13.5X19X0.8-MM THK)
硬垫圈 |
4 | 546 |
| 3T-3422 |
WIRE AS
导线组件 |
1 | 546 |
| 7T-3278 |
HOLDER AS-BRUSH
碳刷座组件 |
1 | 546 |
| 7T-3277 |
COIL AS-FIELD
磁场线圈组件 |
1 | 546 |
| 7T-3454 |
INSULATOR
绝缘体 |
1 | 546 |
| 7T-3271 |
CONNECTOR
接头 |
1 | 546 |
| 7T-3451 |
INSULATOR-TERMINAL
端子绝缘体 |
1 | 546 |
| 8T-8569 |
INSULATOR-TERMINAL
端子绝缘体 |
1 | 546 |
| 5S-7349 |
BOLT (1/4-20X0.5-IN)
螺栓 |
4 | 546 |
| 8T-4205 |
WASHER-HARD (7.2X14.5X2-MM THK)
硬垫圈 |
4 | 546 |
| 8H-1141 |
SHOE-POLE
磁极 |
4 | 546 |
| 3F-0379 |
SCREW-POLE SHOE (3/8-24-THD)
|
8 | 546 |
| 7T-3276 |
ARMATURE AS (24-VOLT)
|
1 | 546 |
| 3E-7775 |
HOUSING AS
壳体组件 |
1 | 546 |
| 4M-1831 |
PLUG-LEVER HOUSING
拨 壳螺塞 |
1 | 546 |
| 7L-2894 |
GASKET
密封垫 |
1 | 546 |
| 036-9823 |
BOLT (1/4-28X1-IN)
螺栓 |
5 | 546 |
| 6N-3826 |
DRIVE AS-MOTOR
马达驱动组件 |
1 | 546 |
| 7T-3974 |
HOUSING AS-DRIVE
驱动壳体组件 |
1 | 546 |
| 7X-3373 |
BOLT (5/16-18X0.88-IN)
螺栓 |
6 | 546 |
| 6V-8378 |
NUT (10-32-THD)
调速螺母 |
2 | 546 |
| 8F-1434 |
LOCKWASHER
锁紧垫圈 |
2 | 546 |
| 8T-0328 |
WASHER-HARD (5.5X10X1-MM THK)
硬垫圈 |
2 | 546 |
| 3T-3434 |
PLUG
O 形圈螺塞 |
6 | 857 |
| 7T-3279 |
HOUSING AS
壳体组件 |
1 | 857 |
| 8T-8566 |
TERMINAL AS
端子组件 |
1 | 857 |
| 6V-8188 |
NUT (1/2-13-THD)
调速螺母 |
4 | 857 |
| 7X-0562 |
WASHER-HARD (13.5X19X0.8-MM THK)
硬垫圈 |
4 | 857 |
| 3T-3422 |
WIRE AS
导线组件 |
1 | 857 |
| 7T-3278 |
HOLDER AS-BRUSH
碳刷座组件 |
1 | 857 |
| 7T-3277 |
COIL AS-FIELD
磁场线圈组件 |
1 | 857 |
| 7T-3454 |
INSULATOR
绝缘体 |
1 | 857 |
| 7T-3271 |
CONNECTOR
接头 |
1 | 857 |
| 7T-3451 |
INSULATOR-TERMINAL
端子绝缘体 |
1 | 857 |
| 8T-8569 |
INSULATOR-TERMINAL
端子绝缘体 |
1 | 857 |
| 5S-7349 |
BOLT (1/4-20X0.5-IN)
螺栓 |
4 | 857 |
| 8T-4205 |
WASHER-HARD (7.2X14.5X2-MM THK)
硬垫圈 |
4 | 857 |
| 8H-1141 |
SHOE-POLE
磁极 |
4 | 857 |
| 3F-0379 |
SCREW-POLE SHOE (3/8-24-THD)
|
8 | 857 |
| 7T-3276 |
ARMATURE AS (24-VOLT)
|
1 | 857 |
| 3E-7775 |
HOUSING AS
壳体组件 |
1 | 857 |
| 4M-1831 |
PLUG-LEVER HOUSING
拨 壳螺塞 |
1 | 857 |
| 7L-2894 |
GASKET
密封垫 |
1 | 857 |
| 036-9823 |
BOLT (1/4-28X1-IN)
螺栓 |
5 | 857 |
| 6N-3826 |
DRIVE AS-MOTOR
马达驱动组件 |
1 | 857 |
| 7T-3974 |
HOUSING AS-DRIVE
驱动壳体组件 |
1 | 857 |
