| Part No. | Name | Qty | Page |
|---|---|---|---|
| 5S-7348 |
SCREW-MACHINE (6-32X0.375-IN)
机器螺钉 |
2 | 1773 |
| 4B-2041 |
NUT (6-32-THD)
调速螺母 |
2 | 1773 |
| 1L-6561 |
PLUG
O 形圈螺塞 |
1 | 1773 |
| 3L-2875 |
CLIP
卡箍 |
1 | 1773 |
| 8F-0244 |
GROMMET
护孔环 |
1 | 1773 |
| 2N-0178 |
PANEL
面板 |
1 | 1773 |
| 7W-2731 |
RETAINER
固定器 |
2 | 1773 |
| 3B-6487 |
COUPLING (PIPE)
连接器 |
1 | 1773 |
| 2N-0179 |
COVER-PANEL
|
1 | 1773 |
| 2N-1287 |
ELBOW-FLARED
扩口弯头 |
1 | 1773 |
| 214-3613 |
ADAPTER
接头 |
1 | 1773 |
| 8B-2664 |
BUSHING-REDUCER
|
1 | 1773 |
| 2N-5848 |
BASE AS
底座组件 |
1 | 1773 |
| 2H-3755 |
BOLT (5/16-18X0.43-IN)
螺栓 |
2 | 1773 |
| 9M-1974 |
WASHER-HARD (8.8X16X2-MM THK)
硬垫圈 |
2 | 1773 |
| 4B-4277 |
WASHER (8.8X17.5X1.6-MM THK)
止推垫圈 |
2 | 1773 |
| 9F-6580 |
BOLT (1/4-20X1.125-IN)
螺栓 |
3 | 1773 |
| 9S-8750 |
NUT-FULL (1/4-20-THD)
全高螺母 |
3 | 1773 |
| 4S-6399 |
CONNECTOR
接头 |
1 | 1773 |
| 4K-8864 |
CLIP
卡箍 |
1 | 1773 |
| 5M-6213 |
PLUG-PIPE
管螺塞 |
1 | 1773 |
| 6V-3507 |
SEAL-RECTANGULAR
矩形密封 |
2 | 1773 |
