| Part No. | Name | Qty | Page |
|---|---|---|---|
| 6N-1876 |
HOUSING AS (RECTIFIER)
壳体组件 |
1 | 942 |
| 9S-2396 |
BUSHING-TERMINAL
轴端衬套 |
1 | 942 |
| 9N-0943 |
PLUG-BEARING WELL
|
1 | 942 |
| 5P-3418 |
BEARING-ROLLER
滚柱轴承 |
1 | 942 |
| 6N-1968 |
STATOR AS
定子组件 |
1 | 942 |
| 9N-0939 |
GROMMET
护孔环 |
1 | 942 |
| 9N-0942 |
PLATE-COVER
|
1 | 942 |
| 2P-5616 |
FRAME-DRIVE END
|
1 | 942 |
| 9S-2390 |
RETAINER
固定器 |
1 | 942 |
| 9N-0937 |
RECTIFIER AS
|
1 | 942 |
| 9S-2302 |
ROTOR AS
转子组件 |
1 | 942 |
| 5P-7807 |
BALL BEARING
球轴承 |
1 | 942 |
| 100-6531 |
FAN-ALTERNATOR (11-BLADE)
|
1 | 942 |
| 5P-3419 |
RACE-BEARING INNER
|
1 | 942 |
| 7F-7621 |
WASHER (0.635X1.25X0.09-IN THK)
止推垫圈 |
1 | 942 |
| 2K-4821 |
LOCKNUT (5/8-18-THD)
锁紧螺母 |
1 | 942 |
| 6N-1945 |
COIL AS-FIELD
磁场线圈组件 |
1 | 942 |
| 9X-2500 |
SCREW-HEX FLANGE (10-24X38.1-MM)
|
4 | 942 |
| 9N-3388 |
BOLT (10-24X0.75-IN)
螺栓 |
5 | 942 |
| 100-6532 |
COLLAR-ALTERNATOR
|
1 | 942 |
| 9S-2009 |
BOLT-FLANGE HEAD (10-24X3.625-IN)
法兰头螺栓 |
4 | 942 |
| 6N-1944 |
DIODE AS
二极管组件 |
1 | 942 |
| 6N-1870 |
SCREW AS (8-32X34-MM)
自攻螺钉组件 |
2 | 942 |
| 8T-0328 |
WASHER-HARD (5.5X10X1-MM THK)
硬垫圈 |
2 | 942 |
| 9S-2544 |
SCREW-HEX HEAD (8-32X11.13-MM)
|
7 | 942 |
| 9B-7233 |
LOCKWASHER
锁紧垫圈 |
11 | 942 |
| 4B-2043 |
NUT (8-32-THD)
调速螺母 |
4 | 942 |
| 6V-8187 |
NUT (1/4-28-THD)
调速螺母 |
2 | 942 |
| 1H-3244 |
LOCKWASHER
锁紧垫圈 |
2 | 942 |
| 6N-1925 |
BRACKET
支架 |
1 | 942 |
| 6N-1946 |
CAPACITOR AS
|
1 | 942 |
| 6N-1872 |
SCREW AS (8-32X1.25-IN)
自攻螺钉组件 |
3 | 942 |
| 3T-6354 |
REGULATOR AS-VOLTAGE (24-VOLT) (ALTERNATOR)
|
1 | 942 |
| 6N-1873 |
LEAD AS
|
1 | 942 |
| 8T-4205 |
WASHER-HARD (7.2X14.5X2-MM THK)
硬垫圈 |
2 | 942 |
| 6N-1871 |
LEAD AS
|
1 | 942 |
| 8M-6701 |
WASHER (0.281X0.5X0.032-IN THK)
止推垫圈 |
3 | 942 |
| 6N-1856 |
BUSHING-TERMINAL
轴端衬套 |
4 | 942 |
